R-1W
Radial Agricultural Tyres
Construction RADIAL
Service Tractor Service
Lower aspect ratio design brings better response ondriving, and provides better traction
Larger contact area design can reduce soil compaction
Radial tire with lower pressure can reduce the soil com-paction significantly.
| Size | Load index | Speed index | IND | Rim | Section width | Ovearall diameter | Load capacity | Inflation pressure | Tread depth | Type | ||||
| mm | inch | mm | inch | kg | kPa | psi | mm | 32nds | ||||||
| 280/70R20 | 116/113 | A8/B | R-1W | W9 | 282 | 11.1 | 900 | 35.4 | 1250 | 240 | 35 | 35.5 | 45 | TL |
| 360/70R24 | 122/119 | A8/B | R-1W | W11 | 357 | 14.1 | 1152 | 45.4 | 1500 | 160 | 23 | 42 | 53 | TL |
| 360/70R24 | 127/124 | A8/B | R-1W | W11 | 357 | 14.1 | 1152 | 45.4 | 1750 | 240 | 35 | 42 | 53 | TL |
| 380/70R24 | 125/125 | A8/B | R-1W | W12 | 380 | 15.0 | 1190 | 46.9 | 1650 | 160 | 23 | 43 | 54 | TL |
| 420/70R24 | 130/127 | A8/B | R-1W | W13 | 418 | 16.5 | 1248 | 49.1 | 1900 | 160 | 23 | 44 | 55 | TL |
| 420/70R24 | 136/133 | A8/B | R-1W | W13 | 418 | 16.5 | 1248 | 49.1 | 2240 | 240 | 35 | 44 | 55 | TL |
| 420/70R28 | 133/130 | A8/B | R-1W | W13 | 418 | 16.5 | 1349 | 53.1 | 2060 | 160 | 23 | 44 | 55 | TL |
| 420/70R28 | 139/136 | A8/B | R-1W | W13 | 418 | 16.5 | 1349 | 53.1 | 2430 | 240 | 35 | 44 | 55 | TL |
| 480/70R24 | 138/135 | A8/B | R-1W | W15L | 479 | 18.9 | 1316 | 51.8 | 2360 | 160 | 23 | 47 | 59 | TL |
| 480/70R28 | 140/137 | A8/B | R-1W | W15L | 479 | 18.9 | 1421 | 55.9 | 2500 | 160 | 23 | 47 | 59 | TL |
| 480/70R28 | 145/142 | A8/B | R-1W | W15L | 479 | 18.9 | 1421 | 55.9 | 2900 | 240 | 35 | 47 | 59 | TL |
| 480/70R28 | 151/148 | A8/B | R-1W | W15L | 479 | 18.9 | 1421 | 55.9 | 3450 | 320 | 46 | 47 | 59 | TL |
| 480/70R34 | 143/143 | A8/B | R-1W | W15L | 479 | 18.9 | 1580 | 62.2 | 2725 | 160 | 23 | 47 | 59 | TL |
| 480/70R38 | 145/142 | A8/B | R-1W | W15L | 479 | 18.9 | 1681 | 66.2 | 2900 | 160 | 23 | 47 | 59 | TL |
| 520/70R38 | 150/150 | A8/B | R-1W | W16L | 516 | 20.3 | 1749 | 68.9 | 3350 | 160 | 23 | 48 | 60 | TL |
| 580/70R38 | 155/155 | A8/B | R-1W | W18L | 577 | 22.7 | 1827 | 71.9 | 3875 | 160 | 23 | 50 | 63 | TL |
| 580/70R38 | 170/167 | A8/B | R-1W | W18L | 577 | 22.7 | 1827 | 71.9 | 6000 | 280 | 41 | 50 | 63 | TL |
