E-7
Radial Off-the-road Tyre
Consinuction BIAS
Service Dessert Application Sand Service
Shallow tread depth provides excellent heat dissipation.
Designed for Operating on Desert or Soft Ground,as well as Paved Roads.
Rib design provides excellent steering stability andimproved lateral traction.
| Size | Ply rating | TRA code | Rim | Section width (mm) | Overall diamter (mm) | Tread depth (mm) | 50km/h | Type | |
| Load capacity（kg） | Inflation pressure（kPa） | ||||||||
| 18-20 | 14 | E-7 | 14.00T | 455 | 1090 | 16 | 4625 | 360 | TT/TL |
| 20-20 | 16 | E-7 | 14.00T | 505 | 1180 | 17 | 6000 | 360 | TL |
| 22-20 | 14 | E-7 | 17.0 | 555 | 1075 | 18 | 4125 | 280 | TL |
